29×12 Patio Cover Plan Set – Framing, Concrete Footing, and Elevation for DIY or Permit Use

Build a 29×12 ft patio cover the right way with this professional plan set in downloadable PDF format.

This complete bundle includes:

✅ Framing Plan – rafter layout, beam spacing, post dimensions, ledger attachment, ties

✅ Concrete Plan – footer length/depth, slab details, PSI requirements, and rebar placement

✅ Front Elevation – showing post height, fascia, and roof style

🛠️ Wgats included?:

Structure Size: 29’3″ wide × 12’6″ deep

Roofing

Framing
Posts

Concrete

📌 Perfect for:

Homeowners applying for permits

DIYers wanting to build a safe, code-compliant structure

Contractors needing a solid starting plan

🔧 Format: 17″x11″ printable PDF

🛑 Note: These plans are based on a real-world approved project, but local codes vary. Always confirm with your local building department before construction.

✍️ Need this plan adjusted to your backyard? I offer quick customization. Send me your sketch or dimensions!
